1. Machine by PLC centralized control (a vector motors), and centralized operation of the whole system using a touch screen interface.
Unwinding adopts PLC set away automatic control powder brake to achieve constant put tension control by PLC automatically calculates the roll diameter.
3. Traction transmission adopts vector inverter motor, constant line speed control.
Winding drive adopts PLC driven up and down the magnetic powder clutch winding taper tension control by PLC automatically calculates the volume diameter.
5 Unwinding shaft device inflatable axis.
6. System with preset meter given volume the diameter calculation decile cut function.
Incidental EPC correcting device can accurately control the end face of the accuracy.
8 This machine is commonly used packaging material of the composite film, the monomer film, aluminum foil, paper and other sub-parallel machining Slitter
2.9 The whole machine adopts timing
The main technical parameters
Model
HXBFQ-700
HXBFQ-1100
HXBFQ-1300
Maximum width slitting coils
700mm
1100mm
1300mm
Slitting coils largest diameter
¦µ600mm
¦µ600mm
¦µ600mm
Slitting coil width
30-600mm
30-1000mm
30-1200mm
Slitting speed
5-200m/min
5-200m/min
5-200m/min
Corrective error
<¡À 0.5mm
<¡À 0.5mm
<¡À 0.5mm
Total power
3kw
4kw
4kw
Overall weight
1200kg
1500kg
1800kg
Dimensions
2200x1500x1400mm
2600x1500x1400mm
2800x1500x1400mm
|
